Energy monitors are devices designed to track, measure, and analyze electrical energy consumption in real-time. They provide valuable insights into power usage patterns, helping industries and businesses optimize energy efficiency, reduce costs, and support sustainability goals.

Key Features:

• Accuracy Class 1.0, 0.5 as per IEC 62052-11/ IEC 62053-22
• G Smart Sensor indicator for Generator running mode
• Monitors electrical parameters : Voltage, Amps, F, PF, W/VA
• Monitors Integrated Parameters :  Wh/Vah Utility & Generator separately
• Monitors Runhours & On hours Utility & Generator Separately, Interrupts
• Demand Monitoring
• Color coded analog load bar indicators
• CT Reversal : Auto correction of energy integration in Star (WYE) mode
• User programmable
          – Delta/STAR/2Ph
          –  PT/ CT primary & Secondary
          – Wh/Vah Billing options
• Turbo Key for one touch operation & Setup
• UL, C UL Listed, CE, C-Tick certified
• Metering voltage inputs range from 80 to 600V ac L-LRS485 communication port with Modbus RTU protocol

Benefits:

• Accurate Energy Billing for Generator usage
• Track Generator overloading using Load bars
• G Smart Sensor supports multiple generator paralleling and Bus islanding schemes
• Reduce energy costs by tracking energy consumption and backup of integrated parameters
• Unique 8 Segment, 3 Line LED Display helps  readable from larger distances
• Auto Scaling Capability in variance of Kilo, Mega, Giga
• User Selectable default display page through keypad lock
• Safeguard access to setup parameters with unique password protection
• Ensure accurate wiring using the terminal board labeling
• Seamless integration into any modbus compatible SCADA- Energy Management System (EMS)

Applications

• Suitable for dual source  energy  billing for any industry segment
• Commercial, Residential buildings, Hotels
• Control Panels
• Genset Panels
• Power Distribution Panels
